CONSTRUCTIONAL FEATURES
Pressure gauge for all non-corrosive fluids at temperatures -10°C to +80°C.
Precision amplifier movement in brass
MATERIAL
Case: 42mm, Black Steel case with Acrylic snap-in lens.
Movement: Brass.
Connection: 1/8'' BSPT, NPT or BSP , brass CenterBack Connector.
Ranges: Vacuum compound and pressure gauge -1bar ~ 0 and 0 ~ 1bar to 25bar.
Protection degree IP32
Accuracy 3-2-3%% Full Scale
Particularly suitable for compressors, pressure reducers, pumps and any other use in the plant and industrial air-operating sector.
